Stilt + 4 Floors in Delhi: What the Rules Allow on Residential Plots

On a residential plot in Delhi, the master plan permits a stilt floor for parking plus four floors above it, within a 17.5 metre height cap and the plot's FAR, and since the Master Plan for Delhi 2047 was notified on 20 August 2026 the stilt is no longer optional on plots above 100 sqm and up to 750 sqm. The format is common for new builder floors across the city: parking at ground level, four independent floors above, and the plot's full development potential used. But the rules have moving parts (height caps, dwelling unit limits, parking requirements) and they change, as the new master plan shows, so treat the numbers here as the ones your architect must confirm for your plot with the MCD before design begins. This guide explains how the format works and the structural risk to check before anything else. Lifts are now common in the format; our home lift guide covers the permissions and the shaft. What happens when a building goes beyond these limits is covered in our guide to MCD notices, sealing and regularisation.

What Exactly Is a Stilt Floor?

A stilt floor is an open ground level of columns with no enclosing walls, used for parking. The Unified Building Bye-Laws define it as the non-habitable part of a building above ground level, on structural columns, with at least two sides open, for parking cars, scooters and cycles and for landscaping (clause 1.4.111), and they set its clear height at a minimum of 2.4 metres to the underside of the beam and a maximum of 2.7 metres to the underside of the slab (clause 7.15.1). A stilt built that way and used for parking is left out of FAR, though it counts toward the building's height (MPD-2047 Table 7.2, control (v)), which is what makes four residential floors above it possible. The moment a stilt is enclosed and converted into a room, shop, or living space, it stops being a stilt in the eyes of the law and becomes an unauthorised floor, a violation MCD can act on.

How Tall Can You Build?

MPD-2047 caps a house on a residential plot at 15 metres, ground plus three floors, where there is no stilt parking, and at 17.5 metres, stilt plus four floors, where there is (Table 7.2, control (iv)); the extra 2.5 metres is what accommodates the stilt level. Control (vi) then makes the stilt compulsory on plots above 100 sqm and up to 750 sqm, so on the 150 and 200 gaj plots most builder floors stand on, a new building goes up over a stilt whatever its number of floors; on plots of 100 sqm and below it remains a choice, and above 750 sqm the parking may go in the setbacks or a stilt. The plan's own exceptions are narrow: the compulsory stilt does not apply in the notified heritage areas of the Walled City (para 3.3.1), and the mixed-use rules make stilts optional on plots along the main access road that carry a non-residential use (para 13.4.9). Within the envelope, a stilt of 2.4 to 2.7 metres plus four floors fits comfortably. Height is measured per the bye-law definitions, and plots in special zones (near protected monuments, in the airport funnel, in heritage areas) face stricter caps, so the first design step is always confirming what applies to your specific plot.

How Many Dwelling Units and How Much Area Are Allowed?

Two separate limits control what you can build. FAR (Floor Area Ratio) caps the total built-up area, and it varies by plot size category under the master plan. The density norms separately cap the number of dwelling units per plot: MPD-2047 allows three on plots up to 50 sqm, four above 50 and up to 250 sqm, and five above 250 and up to 750 sqm, one fewer than MPD-2021 allowed in that band. Parking adds a third constraint, and it follows plot size rather than the number of units: one equivalent car space on plots up to 250 sqm, two above 250 and up to 300 sqm, and one for every 100 sqm of FAR area on plots above 300 sqm, all within the plot (Table 11.7). The stilt is where that parking usually goes. These three numbers together (FAR, dwelling units, parking) determine whether your plot supports four full independent floors or something less, and they are the numbers to have your architect confirm in writing at the start, as part of the MCD approval process. Our plot-size guide tabulates them for 100, 150 and 200 gaj plots.

The Structural Risk Nobody Mentions: The Soft Storey

Here is what matters as much as any bye-law: a stilt building is structurally a 'soft storey' building. The open ground level (columns without walls) is dramatically more flexible than the wall-stiffened floors above, and in an earthquake the deformation concentrates in exactly that level. Soft storeys are a well-known earthquake weakness, and Delhi sits in seismic zone IV. It is also a known engineering problem with established remedies: the bye-laws note that shear walls, bracing or other structural provisions under IS 1893 (Part 1), IS 13920 and IS 4326 may be provided to reduce the soft-storey effect in the stilt area (bye-law 7.15.2, note 1), and the seismic design addresses it through measures like stronger and larger columns at the stilt level and properly designed shear walls around stair and lift cores. But it must actually be engineered, not copied from the last site's drawings, and with the stilt now compulsory on plots above 100 sqm and up to 750 sqm it is a question for every new house of that size, not just for builder floors. When evaluating a builder for a stilt + 4 project, ask one question: how is the soft storey addressed in the structural design? A builder who cannot answer specifically should not be building five levels in zone IV. What zone IV asks of the whole frame, not just the stilt, is set out in our earthquake-resistant construction guide.

Is Stilt + 4 Worth It for Your Plot?

Financially, the case can be strong. Four floors on one plot means rental income or family accommodation at a scale a two-floor house cannot match, and parking, scarce in many Delhi colonies, is built in rather than fought over on the street. The costs are real too: deeper foundations and heavier structure than a G+1 house, lift installation for the upper floors to be rentable at good rates, and a longer construction timeline. For plot owners weighing redevelopment, the comparison worth running is stilt + 4 against a smaller building over the same stilt: the incremental cost of the extra floors against the incremental rent, for your specific location's rental market. Our comparison of builder floors versus independent houses works through the same trade-offs.

Approval Checklist Before You Design

Before any drawings are commissioned: confirm with your architect which rules apply to your plot (MPD-2047 for a new sanction, while a plan approved before 20 August 2026 continues under the earlier norms) and the bye-law position on stilt + 4 for your plot category (the rules change, and a 2022 Supreme Court ruling on the fire position of stilt buildings rested on wording the new plan does not repeat, as our Fire NOC guide explains; verify, do not assume); confirm FAR, dwelling unit count, parking and the stilt for your plot size; check for special-zone restrictions on height; and if the plot has an existing structure, factor in its demolition, which also needs notice to the sanctioning authority on the common application form (bye-law 2.1). Plans that get these right give the sanctioning authority little to query; plans that assume invite query memos.
